    UVOZ-1200 Ozone Gas Analyzer Accurate Measurement By Photometric Absorption


    UVOZ-1200C Ozone Gas Analyzer


    OVERVIEW

    The UVOZ-1200 uses an advanced dual-light UV light source system with a lamp intelligent management system, which enables the UV lamp to reach the measurement state quickly after switching on. Accurate measurement by photometric absorption principle according to Lambert-Beer's law. Foreign long life UV light source system (wavelength 253.7nm), Indoor installation with power and signal terminals. Built-in temperature and pressure compensation and display, with automatic compensation of the light source. User can choose between manual zero calibration and automatic zero calibration according to the operating status, automatic zero calibration time can be set.


    FEATURES

    • The core component adopts UV long life light source system with high transmittance quartz sheet to ensure the stability of the zero point and prevent the zero point drift from affecting the accuracy of the detection concentration.
    • According to the foreign light cell technology design of pressure-resistant, impact-resistant independent light cell structure, zero calibration operation gas flow, pressure, flow rate remains unchanged, to prevent the impact of airflow on the zero calibration, without closing the ozone inlet can complete the zero calibration operation, to ensure that the equipment can be 24 hours a day continuous operation.
    • Display units: g/Nm3, mg/NL, %WT, ppm , mg/Nm3 optional.
    • HD colour touch screen, high concentration range setting for incoming gas mass flow rate, real time display of yield.

    APPLICATION

    It is mainly used for continuous detection of ozone gas in various industrial environments, and can also be used to detect ozone gas in operating pipelines, vessels and other environments.


    SPECIFICATION

    ModelUVOZ-1200
    Measuring range0-200g/Nm3
    Optional ranges0-300g/Nm3, 0-100g/Nm3, 0-50g/Nm3, 0-1000ppm
    Sampling methodpositive pressure sampling, negative pressure sampling (optional)
    Display interface4.3" touch screen operator interface
    Content interfaceOzone concentration, temperature, pressure
    Display unitsg/Nm3, mg/NL, %WT optional
    Display resolution0.01g/Nm3
    Gas flow0.5L ± 0.2L/min
    Concentration error0.3% FS max
    Linearity error0.2% FS max
    Zero point drift<±0.3%.FS
    Response time0.03 s for signal, 0.3 s for display
    Ambient temperature-20 to 50°C
    Tandem sample apertureΦ8 (8mm*6mm) (optional)
    Bypass sampling apertureΦ6 (6mm*4mm)
    Communication methodRS-485
    Output mode4-20mA (active)
    Power supplyAC 110-220V
    Dimensions160mm (H) x 260mm (W) x 300mm (D);
    Note1mg/L = 1g/m3 = 467PPM.
    Free warranty24 months (mainframe sensor)
